Suction hood Flat Under-Cabinet

Suction hood Flat Under-Cabinet
Kitchen hoods
Suction hood Flat Under-Cabinet

The Flat below wall cabinet Hood was designed to be positioned underneath your kitchen wall units, protecting them from the heat of the wood-burning range cooker or cooker stove. The extensive range of customisation possibilities in terms of styling and dimensions allows all possible needs to be accommodated, from country settings to modern ambiances.


It is the perfect hood if you want to make the most of the space between the kitchen cabinets. In fact, this hood is installed under the cabinets, thus hiding the vent pipe.


Technologies

Touch control Rizzoli Cucine
 60 dB Rizzoli Cucine
 Noise reduction Rizzoli Cucine
 Remote control Rizzoli Cucine
 Barra LED Rizzoli Cucine
 Eco manifacture Rizzoli Cucine
 Steel structure Rizzoli Cucine
 Heat resistant Rizzoli Cucine
 No smell filter Rizzoli Cucine
Suction hood Flat Under-Cabinet
Certifications
Technical Data
Documents
CE Rizzoli cucine
Energy label A++ CAPPE Rizzoli cucine
Energy label A+ CAPPE Rizzoli cucine
Partners
HKI Rizzoli cucine

Technical Specifications

    • Installation: undermount
    • Cladding: Stainless steel/Painted
    • Ducted or air recirculation version
    • Controls: touch or mechanical control panel
    • Timer function
    • Lighting: with LED bars
    • Dishwasher-safe filters
    • Resistant to high temperatures
    • Remote control (optional)
    • Extraction rate: 440/875 m3/h
    • Noise level: 60/65 dB
    • Power consumption: from 149.8 to 308.2 W
    • Speed settings: 4
    • Outlet: ø 120/150 mm



Technical Data

CPS6

CPS6
C1/L1 = Version with 445 m3/h motor installed in the body of the hood

C2/L2 = Version with 910 m3/h motor installed outside the body of the hood

A from 400 to 600 mm
B 500 mm
C1 from 130 to 300 mm
C2 from 70(1) to 300 mm
L1 from 75 to 400 mm
L2 85 mm
X (2)
Ø outlet 120/150 mm
Max suction power (W)  137/290 W
LED Power ( (W) 4,8 W


(1) 100 mm with Epoka, Variant border.
(2) Vent position upon request.

The dimensions in the table are purely indicative. Every hood is built to the dimensions and specifications provided by the customer (subject to feasibility check).

CPS8

CPS8
C1/L1 = Version with 445 m3/h motor installed in the body of the hood

C2/L2 = Version with 910 m3/h motor installed outside the body of the hood

A from 601 to 800 mm
B 500 mm
C1 from 130 to 300 mm
C2 from 70(1) to 300 mm
L1 from 75 to 400 mm
L2 85 mm
X (2)
Ø outlet 120/150 mm
Max suction power (W)  137/290 W
LED Power ( (W) 6,7 W


(1) 100 mm with Epoka, Variant border.
(2) Vent position upon request.

The dimensions in the table are purely indicative. Every hood is built to the dimensions and specifications provided by the customer (subject to feasibility check).

CPS9

CPS9
C1/L1 = Version with 445 m3/h motor installed in the body of the hood

C2/L2 = Version with 910 m3/h motor installed outside the body of the hood

A from 801 to 900 mm
B 500 mm
C1 from 130 to 300 mm
C2 from 70(1) to 300 mm
L1 from 75 to 400 mm
L2 85 mm
X (2)
Ø outlet 120/150 mm
Max suction power (W)  137/290 W
LED Power ( (W) 6,7 W


(1) 100 mm with Epoka, Variant border.
(2) Vent position upon request.

The dimensions in the table are purely indicative. Every hood is built to the dimensions and specifications provided by the customer (subject to feasibility check).

CPS12

CPS12
C1/L1 = Version with 445 m3/h motor installed in the body of the hood

C2/L2 = Version with 910 m3/h motor installed outside the body of the hood

A from 901 to 1200 mm
B 500 mm
C1 from 130 to 300 mm
C2 from 70(1) to 300 mm
L1 from 75 to 400 mm
L2 85 mm
X (2)
Ø outlet 120/150 mm
Max suction power (W)  137/290 W
LED Power ( (W) 9,6 W


(1) 100 mm with Epoka, Variant border.
(2) Vent position upon request.

The dimensions in the table are purely indicative. Every hood is built to the dimensions and specifications provided by the customer (subject to feasibility check).

CPS14

CPS14
C1/L1 = Version with 445 m3/h motor installed in the body of the hood

C2/L2 = Version with 910 m3/h motor installed outside the body of the hood

A from 1201 to 1400 mm
B 500 mm
C1 from 130 to 300 mm
C2 from 70(1) to 300 mm
L1 from 75 to 400 mm
L2 85 mm
X (2)
Ø outlet 120/150 mm
Max suction power (W)  137/290 W
LED Power ( (W) 9,6 W


(1) 100 mm with Epoka, Variant border.
(2) Vent position upon request.

The dimensions in the table are purely indicative. Every hood is built to the dimensions and specifications provided by the customer (subject to feasibility check).

CPS15

CPS15
C1/L1 = Version with 445 m3/h motor installed in the body of the hood

C2/L2 = Version with 910 m3/h motor installed outside the body of the hood

A from 1401 to 1500 mm
B 500 mm
C1 from 130 to 300 mm
C2 from 70(1) to 300 mm
L1 from 75 to 400 mm
L2 85 mm
X (2)
Ø outlet 120/150 mm
Max suction power (W)  137/290 W
LED Power ( (W) 9,6 W


(1) 100 mm with Epoka, Variant border.
(2) Vent position upon request.

The dimensions in the table are purely indicative. Every hood is built to the dimensions and specifications provided by the customer (subject to feasibility check).

CPS18

CPS18
C1/L1 = Version with 445 m3/h motor installed in the body of the hood

C2/L2 = Version with 910 m3/h motor installed outside the body of the hood

A from 1501 to 1800 mm
B 500 mm
C1 from 130 to 300 mm
C2 from 70(1) to 300 mm
L1 from 75 to 400 mm
L2 85 mm
X (2)
Ø outlet 120/150 mm
Max suction power (W)  137/290 W
LED Power ( (W) 13,4 W


(1) 100 mm with Epoka, Variant border.
(2) Vent position upon request.

The dimensions in the table are purely indicative. Every hood is built to the dimensions and specifications provided by the customer (subject to feasibility check).

CPS21

CPS21
C1/L1 = Version with 445 m3/h motor installed in the body of the hood

C2/L2 = Version with 910 m3/h motor installed outside the body of the hood

A from 1801 to 2100 mm
B 500 mm
C1 from 130 to 300 mm
C2 from 70(1) to 300 mm
L1 from 75 to 400 mm
L2 85 mm
X (2)
Ø outlet 120/150 mm
Max suction power (W)  137/290 W
LED Power ( (W) 18,2 W


(1) 100 mm with Epoka, Variant border.
(2) Vent position upon request.

The dimensions in the table are purely indicative. Every hood is built to the dimensions and specifications provided by the customer (subject to feasibility check).
